This repo contains python codes that detects traversible row for agriculture robots
using ShellNet. The model in this repo is a naive pytorch adoption of the authors'
tensorflow release. Note that the very same pipeline could be used for generic
object detection, and semantic segmentation, while this work only concerns about
detecting a single row without row switching.
The purpose of this work is to enable autonomous, LIDAR-based in-row navigation for
agriculture robots. Specifcially, to address the occassions where GPS are not reliable
or not accurate enough. The training data were collected from a vineyard field using
Velodyne's VLP-16, which was mounted on a mobile agriculture robot.
Proposed in 2019, ShellNet was designed to process pointcloud data directly. The
authors introduced a new method called shell convolution. Essentially, it obtains
sorted k nearest neighbor, divides them into D cells, selects the maximum feature
from each cell, and finally combines the features from each cell with a traditio-
nal 1D convolution. The network is then constructed with multi-layers of shellconv
layers, using an encoder-decoder architecture like UNet.
download data using link in ./data/README.md and put them under /data
cd evaluation && python3 evaluate.py --model ../weight/shellnet01/91.pth
change subsriber channel as needed
cd ros && python2.7 row_decection
The model was trained with 150 sets of pointcloud data. The model takes as input
an downsampled pointcloud tensor (1024 x 3), and a label tensor (1024,) with each
element represents one of the N class in [0, N)
The network was mostly trained on data facing forward, with vehicle standing in the center.
The behavior when the vehicle has different orientation is poorer. It could make more
sense to detect vineyard instead of rows.
Also, the KNN implementation of the model is naive, which could be optimized. In addition,
the sampling method in this work is uniform sampling, but some more advanced sampling in
the author's work could also be implemented.
MIT License
